Pilot plant Betulinines

The workshop

Duplicated reactor 30L with cooler

Duplicated reactor 7L

Separatory funnel 25L

Pilot plant 50L and 30L reactor with coolers

Chromatography column 30L

Pilot chromatographic columns

Production equipment for distilled water and pressurised steam

Compressed air storage - compressor Ferrua SBK 5

Reactors from the left - 50L, 30L, 3L, 7L and separatory funnel 20L


Reactors Storage area

Storage area

Ball valve PTFE

Ice maker

Stream generator 19 kW - the heart of the plant

Steam hub

Reservoir for starting materials - birch and plate bark

Reservoir for birch bark for production


Forced circulation evaporator
